ULTIMATE Inclusions and Specifications

Click image below to download Ultimate Inclusions PDF Booket

PLANS AND BUILDING APPROVALS

• • Homeowners warranty.
  • Architectural Plans.
  • Engineering plans
  • Long Service Levy fee.
  • Waste Management Report.
  • Site soil report by Geotechnical Engineer.
  • Site contour survey by a registered Surveyor.
  • Sydney Water Tap-In

SITE PREPARATION

• • Standard site preparation and levelling including, rental of machine for cut and construction of concrete slab on ground.
  • Service Connection – Power, Phone, Water, Sewer, Gas & Stormwater.
  • Conduit for NBN connection.
  • Pegout Survey

PLUMBING AND DRAINAGE

• • All plumbing and drainage as per the plan.
  • All taps and showers to satisfy the energy star rating to be selected from the builder’s nominated premium Range.
  • 2 x garden taps.
  • Supply and install 1 x above ground poly rainwater tanks as per BASIX if required.
  • Supply and install instantaneous hot water system (26L/min) inside the wall.
  • Standard round PVC downpipes.
  • 1 x gas point.

CONCRETE SLAB

• • Structural engineer designed “H1” class concrete slab.
  • All piering, up to 1 m ($176plm extra)
  • Superior TERMITE BARRIER to all slab penetrations and termite barrier to the perimeter of the home.
  • Drop edge beams are charged at $ 770 per square metre.
  • Driveway (50sqm)

FRAME AND WALL LINING

• • T2 Termite treated frames.
  • 450mm eaves or as noted on architectural plans.
  • 90mm external and 90mm internal stud frames to the ground floor and first floor.
  • Up to 3300mm high ceilings for the ground floor & first floor.
  • 300mm engineered joist system.
  • 13mm plasterboard linings to walls and ceilings.
  • Hebel flooring 75mm to first floor
  • 6mm villaboard to wet areas.
  • Tiled niches to all bathrooms and bathtubs.
  • Drop ceiling or bulkhead to the kitchen.

BRICKWORK

• • Fully rendered (acrylic) on common bricks

WINDOWS

• • Powder-coated Aluminium windows (DOUBLE GLAZED) and sliding doors with a choice of colors from a nominated builder’s range (1.2 x the squares of the house, excludes bifold doors and windows).
  • Flush sliding door with sub-sil drain

ROOFING, GUTTERS, AND FACIA

• • Tiled roof from the Monier Atura range
  • Colorbond roof
  • Anticon roofing blanket.
  • Colourbond metal fascia and gutter from a selection of ColorBond colours.

INSULATION

• • Thermal batts to external walls including the internal wall between garage & house.
  • Thermal batts to ceilings.

DOOR ARCHITRAVE AND SKIRTING

• • 3000mm  x1500mm front entrance door with clear glass in painted/stained finish.
  • 2700mm Laundry entrance door solid timber.
  • Solid Timber internal doors 2700mm in stain or paint finish.
  • Shadowline or square set to doors and windows in the paint finish.
  • Shadowline skirting in the paint finish.

DOOR HARDWARE

• • Enterance Door: Samsung SHP-DP710 Pull-doorlock
  • Internal Doors: All bathrooms and WCs feature lever handles with privacy sets.
  • Wall/door stops to all doors.
  • Entrance equipped with a Video Intercom.

GARAGE DOORS

• • Remote-controlled  Aluminium sectional overhead door. Choice of colours.
  • Epoxy floor coating

ELECTRICAL

• • Hard-wired smoke detectors provided with battery backup.
  • Two telephone points.
  • Subfloor heating
  • Three-phase underground mains provision with single-phase switchboard.
  • Downlights as per the requirement to the following areas:
    • All internal areas
    • Porch
    • Alfresco
    • Garage
    • Balcony
  • CAT & data point to the internal wall of the garage and TV.
  • Earth leakage circuit breaker for lights and power.
  • 1 light point to each room.
  • 2-way switch to stairs only
  • 2 Double power points to all rooms including the garage.
  • Power provision Single GPOI for Fridge, Dishwasher, Microwave, and Rangehood.
  • 3 TV points
  • External lights x5
  • External LED lights
  • Sensor lights external x4

STAIRCASE

• • Steel Mono stringer stairs
  • Glass balustrade as needed.

FLOOR COVERING

• • Floor tiles (1600×800, 1200×600, 600×600, 800×800) to ground floor (selected from nominated Builders range ACME Tiles and Beaumont Tiles).
  • Prefinished engineered /solid TIMBER flooring for the first floor.

TILES

• • Ceiling & Floor tiles to Wet Areas Beaumont Tiles signature Range. (ACME, Beaumont Tiles)
  • Tiling Heights – Bathroom and Ensuite – Floor to ceiling
  • Laundry -600mm high tiling over laundry tub & skirting tiles to the remainder

TAPS AND FITTINGS

• • Parisi lever mixer to all basins.
  • Parisi chrome lever mixer and outlet to the bath.
  • Parisi overhead square showerhead to all bathrooms 200 mm x 200mm.
  • Washing machine set to laundry.
  • Parisi pull out mixer to the kitchen or butler kitchen and laundry.

KITCHEN

• • Marble look Calcutta or Carrara stone benchtops.
  • 40mm stone benchtops to the kitchen.
  • Polyurethane or Polytec melamine doors in a wide range of colours up to 3000mm high
  • Overhead cupboards for the kitchen and butlers kitchen/pantry.
  • 100mm stone to the island area.
  • Bulkheads to overhead cupboards.
  • Kitchen kickboards as per doors.
  • 3 sets of Pot drawers.
  • Cutlery tray to kitchen drawer (1)
  • One double bowl stainless steel sink with drainer.
  • Island 1200x3000mm.
  • Stone splashback to the kitchen (selected from standard range or Window)
  • Total of 10m kitchen cabinets (floor and walls, island additional)
  • Butlers pantry

APPLIANCES

• • Appliances allowance $50,000. Pick and choose any brand.
  • Gaggenau, Miele, Pitt appliances

FIREPLACE

• • Gas fireplace upto 180cm
  • Stone cladding around the fireplace

AIR CONDITIONING

• Actron or Daikin  Ducted Aircon as per requirement (4 zones).
• Smart zone contollers
• Up to 15 LINEAR ALUMINIUM outlets.

BATHROOM

• 600mm towel rack to bathrooms and ensuite.
• Toilet roll holder to bathrooms, ensuite, and powder room.
• Hand towel ring for powder room.
• White free-standing bath.
• Fan & heater 3 in 1 (for bathrooms & master ensuite).
• In-wall cistern toilet suite with soft close seat.
• Full Frameless shower screens as required.
• LED  bathroom mirrors.

• 100mm stone benchtops to vanities.
• Laminated doors with PVC edges in a wide range of colours.
• Semi-recessed or top-mounted basins.

LAUNDRY

• • Single bowl with pull out Kitchen mixer and Melamine/polyurethene cabinets.
  • 40 mm Benchtop.

WARDROBES AND LINEN

• • Glass sliding 2400mm doors to standard bedroom robes with one set of drawers and melamine shelf & hanging rail.
  • Walk-in robes in Master with melamine shelves and two sets of drawers (total 5 mts length and 2400 height)
  • White Melamine shelves four to linen cupboards.

PAINTING

• • 3 coat paint system to internal walls including 2 external paint colours.
  • 1 ceiling colour.
  • Gloss paint to doors and internal woodwork.
  • Feature walls panels

ALFRESCO

• • Slip-resistant tiled  floor (Selected from nominated Builder’s range Beaumont Tiles)
  • Downlights

SAFETY

• • Scaffold to the perimeter of the house.
  • Safety Rail to the perimeter of the first floor as required. Stair and Void Protection.

WARRANTY

• • 6 years structural.
  • 13 weeks defect liability period
  • 2 years maintenance period
  • Appliances and fittings as per manufacturers.
